Prerequisites
In order to use this guide, I assume you already have:
- A Kubernetes Cluster up and running
- Botkube installed on your cluster
- Slack App for Botkube installed in your workspace
In case you don’t fullfill all of them, please follow the links attached for the setup.
Notifications
Imagine you’re managing a Kubernetes cluster and want to keep an eye on any errors occurring in your apps. With Botkube, we can get chat notifications about issues detected from Kubernetes events. This approach improves the platform team’s reaction time quite a bit.
In the screenshot below for instance, you can see an error notified on Slack due to an OutOfMemory issue:
Configuration
The configuration can be created in Botkube’s global-config configmap if you are using the default structure. There you can add your event sources.
Since the global configmap could become quite big and needs proper indentation and formatting, I suggest using Kustomize to generate it. It allows the creation of a plain YAML file for Botkube’s config, which can be then used to generate a regular Kubernetes configmap.
Example of the kustomization file needed to generate the configmap from a file called global_config.yaml:
apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization
generatorOptions:
disableNameSuffixHash: true
configMapGenerator:
- name: botkube-global-config
files:
- global_config.yaml
The following snippet from the global-config configMap shows an event source, which is what we want to notify in our chat based on Kubernetes events. We need to use Botkube’s kubernetes plugin and configure how we want to filter and classify events.
# global_config.yaml
sources:
platform-team-err: # name of the source
displayName: Errors with resources logs
botkube/kubernetes: # Botkube plugin
enabled: true
context: # RBAC Config
rbac:
group:
prefix: ""
type: Static
static:
values:
- botkube-src-kubernetes
config:
filters:
objectAnnotationChecker: true
nodeEventsChecker: true
event:
types:
- error # We want error events
reason:
include:
- .*
namespaces:
include:
- .* # All namespaces
exclude:
- kube-.*
resources: # Which resources do we want?
- type: v1/pods
- type: apps/v1/deployments
- type: apps/v1/statefulsets
- type: apps/v1/daemonsets
- type: batch/v1/jobs
In the previous configuration we are interested in events which can be classified as errors from all namespaces except from kube-system. Additionally we define which resources we want to get notifications from, for instance, Pods, Deployments, StatefulSets and DaemonSets.
Botkube Deployment Example
Here you can see the botkube-global-config configmap mounted into our Botkube Pod:
apiVersion: apps/v1
kind: Deployment
metadata:
name: botkube
spec:
replicas: 1
revisionHistoryLimit: 5
strategy:
type: Recreate # WARN: RollingUpdate doesn't work with SocketSlack integration as it requires only a single connection to Slack API at a time.
selector:
matchLabels:
app: botkube
template:
metadata:
labels:
app: botkube
spec:
serviceAccountName: botkube
securityContext:
runAsNonRoot: true
runAsUser: 1001
runAsGroup: 1001
fsGroup: 1001
seccompProfile:
type: RuntimeDefault
containers:
- name: botkube
image: ghcr.io/kubeshop/botkube:v1.13.0
imagePullPolicy: IfNotPresent
envFrom:
- configMapRef:
name: botkube-envs
resources:
requests:
cpu: 500m
memory: 1Gi
limits:
cpu: 500m
memory: 1Gi
ports:
- name: metrics
containerPort: 2112
- name: lifecycle
containerPort: 2113
- name: health
containerPort: 2114
- name: webhook
containerPort: 2115
readinessProbe:
httpGet:
path: /healthz
port: health
initialDelaySeconds: 10
periodSeconds: 10
timeoutSeconds: 9
successThreshold: 1
failureThreshold: 15
livenessProbe:
httpGet:
path: /healthz
port: health
initialDelaySeconds: 10
periodSeconds: 10
timeoutSeconds: 9
successThreshold: 1
failureThreshold: 15
securityContext:
privileged: false
allowPrivilegeEscalation: false
capabilities:
drop:
- ALL
readOnlyRootFilesystem: true
volumeMounts:
- name: startup-config
mountPath: /startup-config
- name: config-volume
mountPath: /config
- name: cache
mountPath: /.kube/cache
- name: cache-volume
mountPath: /tmp
volumes:
# Startup ConfigMap need to be mounted separately to avoid triggering Config Watcher.
# When using `projected.sources`, each file is removed and added when any ConfigMap/Secret changes.
- name: startup-config
configMap:
name: botkube-startup-config
- name: config-volume
projected:
sources:
- configMap:
name: botkube-global-config
- secret:
name: botkube-communication
- configMap:
name: botkube-runtime-config
- name: cache
emptyDir: {}
- name: cache-volume
emptyDir: {}
Route Notifications to Slack
The final important piece of configuration is needed to route notifications to our Slack channels. It is configured in a Secret called botkube-communication, which specifies the chat platform, in this case Slack, together with the required credentials for the Slack app and information about the channels.
In this case, we notify in the channel called alerts-platform-team and we bind the event source to the channel.
apiVersion: v1
kind: Secret
metadata:
name: botkube-communication
stringData:
comm_config.yaml: |
communications:
slack-platform-alerts:
socketSlack:
enabled: true
# APP: Botkube - METHOD: Socket mode
botToken: some-bot-token
appToken: some-app-token
channels:
alerts-platform-team:
name: alerts-platform-team
bindings:
sources:
- platform-team-err
